Robinia M 4300, Forestry winch powered by cardan shaft

In stock 0.0 0 reviews Item no.: A01-5268

Parameters

Weight
218 kg
Minimum HP
35 hp
CAT
I, II
RPM
540 rpm
Dimensions
1200x450x1900 mm
Capacity (kg)
4285 kg
Max Pulling Power
42 KN
Steel cable diameter
9 mm
Cable length
60 m
Pulling speed
0.9 m/s

Description

Powerful and time-saving. For the forester with challenging forest sites. Broadly deployable forest winch, ideal for locations where manoeuvring with a tractor is difficult. Safe and secure transport of felled timber from the working area with minimum physical strain on the operators. Ideal for production forest managers, road authorities and stewards of forest estates.

  • Pull-out force regulator
  • Automatic safety brake
  • Heavy duty 12A roller chain drive
  • Single disc slip clutch
  • 4 Chain anchor slots for log towing
  • D2 Trailer hitch for light trailer

Reviews

0.0 0 reviews

We only show reviews from genuine buyers!

No reviews yet for this product!

Help others out and tell them what you think of this product.

Please sign in to review this product!

Your name
Email address
Rating (1-5) Your review

Warranty

Under European Union warranty rules we provide 2 years of warranty for private individuals and 1 year for companies and businesses. Manufacturers may, however, set their own warranty periods.

Warranty handling

In case of a warranty issue, please fill in the warranty form. Once reported, we send the case for review and reply within 48 hours with the next steps for your case.

Fill in the warranty form

Have a question? We can help!

Call us on +36 56 770 010 or send an email to sales@agrohof.com — our colleagues reply within 2-4 hours!

Exploded view

1
AARDENBURG
Driven sprocket shaft welded parts

Item no.: A1-27514 · 1 pcs

Available to order
Price on request
2
AARDENBURG
Spring

Item no.: A1-27515 · 1 pcs

Available to order
Price on request
3
AARDENBURG
Bushing

Item no.: A1-27516 · 1 pcs

Available to order
Price on request
4
AARDENBURG
Angular contact ball bearings 7306 AC/DB

Item no.: A1-27517 · 2 pcs

Available to order
Price on request
5
AARDENBURG
Friction plate assembly

Item no.: A1-27518 · 1 pcs

Available to order
Price on request
6
AARDENBURG
Ring welded parts

Item no.: A1-27519 · 1 pcs

Available to order
Price on request
7
AARDENBURG
Roller weldment

Item no.: A1-27520 · 1 pcs

Available to order
Price on request
8
AARDENBURG
Angular contact ball bearings 7306 AC

Item no.: A1-27521 · 1 pcs

Available to order
Price on request
9
AARDENBURG
Nut M10

Item no.: A1-27522 · 10 pcs

Available to order
Price on request
10
AARDENBURG
Bolt M10*25

Item no.: A1-27523 · 4 pcs

Available to order
Price on request
11
AARDENBURG
Bolt M14*60

Item no.: A1-27524 · 1 pcs

Available to order
Price on request
12
AARDENBURG
Wedge wire connector

Item no.: A1-27525 · 1 pcs

Available to order
Price on request
13
AARDENBURG
Connecting ring

Item no.: A1-27526 · 1 pcs

Available to order
Price on request
14
AARDENBURG
Nut M14

Item no.: A1-27527 · 1 pcs

Available to order
Price on request
15
AARDENBURG
Compacted wire cable 9-6xK25Fi+IWRC-1960B

Item no.: A1-27528 · 1 pcs

Available to order
Price on request
16
AARDENBURG
Universal ring M12

Item no.: A1-27529 · 1 pcs

Available to order
Price on request
17
AARDENBURG
Pull hook

Item no.: A1-27530 · 1 pcs

Available to order
Price on request
18
AARDENBURG
Nut M12

Item no.: A1-27531 · 1 pcs

Available to order
Price on request
19
AARDENBURG
Cable pressure plate

Item no.: A1-27532 · 1 pcs

Available to order
Price on request
20
AARDENBURG
Spring washer 6

Item no.: A1-25003 · 4 pcs

Available to order
Price on request
21
AARDENBURG
Bolt M6*16

Item no.: A1-27533 · 4 pcs

Available to order
Price on request
22
AARDENBURG
Nut M12

Item no.: A1-27534 · 7 pcs

Available to order
Price on request
23
AARDENBURG
Link

Item no.: A1-27535 · 2 pcs

Available to order
Price on request
24
AARDENBURG
Bushing

Item no.: A1-27536 · 2 pcs

Available to order
Price on request
25
AARDENBURG
Bolt M12*40

Item no.: A1-25873 · 2 pcs

Available to order
Price on request
26
AARDENBURG
Handle

Item no.: A1-27537 · 1 pcs

Available to order
Price on request
27
AARDENBURG
Rocker arm welded parts

Item no.: A1-27538 · 1 pcs

Available to order
Price on request
28
AARDENBURG
Top pillar

Item no.: A1-27539 · 3 pcs

Available to order
Price on request
29
AARDENBURG
Bolt M16*65

Item no.: A1-27540 · 1 pcs

Available to order
Price on request
30
AARDENBURG
Wire rope guide plate welded parts

Item no.: A1-27541 · 1 pcs

Available to order
Price on request
31
AARDENBURG
Bushing

Item no.: A1-27542 · 1 pcs

Available to order
Price on request
32
AARDENBURG
Bearing 6305-2Z

Item no.: A1-27543 · 1 pcs

Available to order
Price on request
33
AARDENBURG
Washer

Item no.: A1-27544 · 2 pcs

Available to order
Price on request
34
AARDENBURG
Guide wheel

Item no.: A1-27545 · 1 pcs

Available to order
Price on request
35
AARDENBURG
Guide cable frame welded parts

Item no.: A1-27546 · 1 pcs

Available to order
Price on request
36
AARDENBURG
Nut M16

Item no.: A1-27547 · 1 pcs

Available to order
Price on request
37
AARDENBURG
Baffle welded parts

Item no.: A1-27548 · 1 pcs

Available to order
Price on request
38
AARDENBURG
Lock Pin 12

Item no.: A1-27549 · 3 pcs

Available to order
Price on request
39
AARDENBURG
Top Pin

Item no.: A1-27550 · 1 pcs

Available to order
Price on request
40
AARDENBURG
Machine base welded parts

Item no.: A1-27551 · 1 pcs

Available to order
Price on request
41
AARDENBURG
Trailer pin welded parts

Item no.: A1-27552 · 1 pcs

Available to order
Price on request
42
AARDENBURG
R Pin

Item no.: A1-27553 · 1 pcs

Available to order
Price on request
43
AARDENBURG
Bolt M12*50

Item no.: A1-27554 · 1 pcs

Available to order
Price on request
44
AARDENBURG
Grease nipple M8*1

Item no.: A1-27555 · 1 pcs

Available to order
Price on request
45
AARDENBURG
Tie rod fixing plate

Item no.: A1-27556 · 1 pcs

Available to order
Price on request
46
AARDENBURG
Down pin

Item no.: A1-27557 · 2 pcs

Available to order
Price on request
47
AARDENBURG
Bolt M10*65

Item no.: A1-27558 · 1 pcs

Available to order
Price on request
48
AARDENBURG
Tie rod welded parts

Item no.: A1-27559 · 1 pcs

Available to order
Price on request
49
AARDENBURG
Stop plate welded parts

Item no.: A1-27560 · 1 pcs

Available to order
Price on request
50
AARDENBURG
Spring

Item no.: A1-27561 · 1 pcs

Available to order
Price on request
51
AARDENBURG
Front end cover welded parts

Item no.: A1-27562 · 1 pcs

Available to order
Price on request
52
AARDENBURG
Bolt M12*35

Item no.: A1-27563 · 4 pcs

Available to order
Price on request
53
AARDENBURG
Support foot welding parts

Item no.: A1-27564 · 1 pcs

Available to order
Price on request
54
AARDENBURG
Pin

Item no.: A1-27565 · 1 pcs

Available to order
Price on request
55
AARDENBURG
Washer 30

Item no.: A1-27566 · 1 pcs

Available to order
Price on request
56
AARDENBURG
Nut M30

Item no.: A1-27567 · 1 pcs

Available to order
Price on request
57
AARDENBURG
Brake pad assembly

Item no.: A1-27568 · 1 pcs

Available to order
Price on request
58
AARDENBURG
Friction plate compression spring

Item no.: A1-27569 · 1 pcs

Available to order
Price on request
59
AARDENBURG
Adjustment handwheel

Item no.: A1-27570 · 1 pcs

Available to order
Price on request
60
AARDENBURG
Wing nut M10

Item no.: A1-27571 · 1 pcs

Available to order
Price on request
61
AARDENBURG
Chain 12AH-1-74 (reinforced)

Item no.: A1-27572 · 1 pcs

Available to order
Price on request
62
AARDENBURG
Circlip for shaft A30

Item no.: A1-27573 · 1 pcs

Available to order
Price on request
63
AARDENBURG
Bearing 6206-2Z

Item no.: A1-27574 · 2 pcs

Available to order
Price on request
64
AARDENBURG
Bolt M10*35

Item no.: A1-27575 · 4 pcs

Available to order
Price on request
65
AARDENBURG
Washer 10

Item no.: A1-27576 · 4 pcs

Available to order
Price on request
66
AARDENBURG
Spring washer 10

Item no.: A1-27577 · 4 pcs

Available to order
Price on request
67
AARDENBURG
Bearing seat weldment

Item no.: A1-27578 · 1 pcs

Available to order
Price on request
68
AARDENBURG
Nut M12

Item no.: A1-27531 · 3 pcs

Available to order
Price on request
69
AARDENBURG
Input shaft press fitting

Item no.: A1-27579 · 1 pcs

Available to order
Price on request
70
AARDENBURG
Cladding welded parts

Item no.: A1-27580 · 1 pcs

Available to order
Price on request
71
AARDENBURG
Washer 8

Item no.: A1-27581 · 7 pcs

Available to order
Price on request
72
AARDENBURG
Spring washer 8

Item no.: A1-25915 · 7 pcs

Available to order
Price on request
73
AARDENBURG
Bolt M8*20

Item no.: A1-25872 · 7 pcs

Available to order
Price on request
74
AARDENBURG
PTO cover

Item no.: A1-27582 · 1 pcs

Available to order
Price on request
